Overview

Basic Info.

Model NO.	pressboard
Material	Fiberglass
Maximum Voltage	10kv~20kv
Thermal Rating	H 180
Type	Insulation Sheet
Chemistry	Organic Insulation
Classification	Organic Insulating Material
Certification	ISO9001
Brand	Rainyan
Transport Package	Pallet
Specification	0.5mm-40mm
Trademark	rainyan
Origin	China
Production Capacity	100000kg/Day

Packaging & Delivery

Package Size100.00cm * 200.00cm * 40.00cm Package Gross Weight1000.000kg

Product Description

Company Inforamtion

Xuchang Ruiyuan insulation material co.,ltd insist on the
idea " GOOD QULAITY, GOOD SERVICE ". it is establish 20years old.
It is located in Xuchang City, Henan Province, China. From 2010 year old our company begin deal international trade, based on the original business. Till now we import and export to many contries, such as United Kingdom, Germany, France, Ukrain, Bulgaria, Italy, India, Pakistan, Bangladesh, Korea, Brzil and so on.
Our manufacturing technique is leading in this field and well known in the world. Now there are more than 20 product facilities, and 105 staff, including 5 senior technical, 20 intermediate technical. Main products are manufactured on international standard.
Our products mainly used for transformer and electrical motor, we produces insulation paper, insulation board, insulation tape,insulation film and also sales PTFE FR4 PA6 and cable wire.
We will develop with you by best-quality products, warm-hearted service and mutually beneficial cooperation!

High Voltage Electrical Insulation Material Paper Pressboard Insulation Paperboard for Transformer

Product Description

1. Pressboard nature color / red color

electrical insulation pressboard
1 .Description:
electrical insulation pressboard for transformer is made of high quality insulation press board and the glue on both sides to be inserted in between boardsor the adhesive oppointed by customers by hot press process .The maximum dimension is 950*1950.Since 2006 the press board with the large size of 6000*3000mm has been put into production,we can deliver the large size laminated board now,the maximum the dimension is 3000*2000mm .They have better performance obviously than laminated wood in the mechanical strength and insulation strength.
2.Specifications:
1). nominal thicknesses:1mm-5mm
2).nominal length:1000mm*2000mm
3). Moisture Content :1.2-1.3 g/cm3
3. Color:Natural,red


4. Applications: apply in motor electric equipment with high requirement for mechanical strength ,and can be used in transformer oil

5. character
1 resistant to voltage under 110KV
2 IEC641-3-1 STANDARD
3 good mechanical strength
4 flat and smooth surface
5good tenacity

Be made up of 100% pulp vitriol conifer wood, abided by IEC641-3-1 STANDARD, the RED APRICOT thick insulating paperboard has been titled GOOD QUALITY by the LIGHT INDUSTRY MINISTRY and enter into the DATA OF FAMOUS PRODUCT IN CHINA.
It be mainly used in the clapboards of transformers and other insulating components such as insulation tube. It can also be used as the board in electrical usage, such as high/low switch, and the insulating material of home electrical equipment, shoe-making, packing.

Product Parameters

Number	Index		Unit	Standard	Test Result
1	Norminal thickness		mm	2	2.1
2	Norminal Grammage		g/cm3	1.1-1.25	1.14
3	Tensile Strength	MD CD	MPa	≥105 ≥80	119 89
4	Elongation	MD CD	%	≥3.0 ≥4.0	6.9 5.8
5	Breakdown Voltage		KV/mm	≥35	39.8
6	PH VALUE		/	6.0-6.9	8.0
7	Content of water		%	5.0-6.0	5.6
